PCL 2U Rack 4kW Programmable DC Power Supply 20V 200A & 40V 100A to 600V 6.7A

PCL 4kW series 2U rack-mounted programmable DC power supply is a power supply with high power density and flexible control capabilities. It can provide up to 4,000 watts of power in a small physical space (2U height, approximately 8.89cm) and supports a wide range of voltage output from 20V to 600V. At the same time, its standard RS232 and RS485 communication interfaces make it easy to integrate into the automatic test system (ATE) and remotely control the output through a computer. The PCL 4kW Programmable DC Power Supply is very suitable for R&D, production and quality inspection scenarios that have comprehensive requirements for space, power, precision and automated control. The following are its specific application scenarios.

20V 200A 4kW Programmable DC Power Supply PCL4000-20: This power supply is characterized by low voltage and ultra-large current, and is mainly used in test scenarios that require large current drive.

• Aging test of high-power electronic components: Provide continuous high current for relays, contactors, high-power resistors and other devices, conduct long-term aging tests, and screen early faulty products.
• Electrochemistry and surface treatment: As a stable DC source, it is used in electrochemical processes such as precision electroplating, anodizing, electrolysis, and water treatment.

40V 100A 4kW Programmable DC Power Supply PCL4000-40: This power supply has medium-voltage and high-current specifications. The output voltage covers common low-voltage systems such as 12V, 24V, and 36V. It has a wide range of application requirements in automotive electronics, motor drive, battery testing, industrial control and other fields.

• Automotive motor controller testing: Provide power supply for electric power steering (EPS), electronic water pump, electronic fan and other motor controllers to conduct performance verification and aging testing.
• Automotive lighting and audio-visual system testing: Provide high-current power supply for headlights, LED light modules, car audio, etc., and conduct power verification and reliability testing.

100V 40A 4kW Programmable DC Power Supply PCL4000-1H: This power supply has moderate voltage and current, and has a wide range of applications.

• Routine testing of electronic components: Conduct routine electrical performance tests and durability tests on electronic components such as capacitors, resistors, and relays.
• General automated testing: As the core component of automated test equipment (ATE), it provides accurate power supply for circuit boards and electronic modules on the production line.

200V 20A 4kW Programmable DC Power Supply PCL4000-2H: The voltage of this power supply is further increased and is suitable for equipment and devices with higher voltage levels.

• LED lighting and photoelectric testing: Provide drive power for high-power LED modules, LCD backlight modules, etc., conduct aging tests and verify photo-chromatic and electrical parameters.
• Precision circuit board power supply: Provide stable, low-noise precision power supply for optical communication modules, industrial control circuit boards, etc.

400V 10A 4kW Programmable DC Power Supply PCL4000-4H: The voltage of this power supply reaches the high voltage level and is mainly used in high voltage electronic systems and devices.

• High-voltage electronic component testing: Test parameters such as withstand voltage and leakage current on high-voltage capacitors, varistors, IGBT modules and other devices.
• General high-voltage source for scientific research and laboratories: Provide stable and programmable DC power supply for various high-voltage experiments in universities and research institutes.

500V 8A 4kW Programmable DC Power Supply PCL4000-5H: This power supply has a higher voltage and is often used in professional fields that have special voltage requirements.

• Power supply and testing of special high-voltage equipment: Provide power supply and testing for radar systems, airborne equipment, avionics and other equipment that require extremely high power supply stability and reliability.
• High-voltage electronic component empowerment: It is specially used for the forming process of high-voltage components such as tantalum capacitors, that is, the formation of oxide films under high pressure.
